Revo EC 16kW BURNER NEW
Compact burner with InCroX® rotary combustion chamber and EC (BLDC) fan. Mounting window Ø 135 mm. For Class 5 Ecodesign boilers, efficiency up to 99%. An ideal solution for pellet boilers.
Output range
from 4.8 to 16 kW
Combustion chamber
Air and fuel
Electronics and control
Safety
Assembly and service
Specification
Specification
| Minimum power | 4.8 kW |
|---|---|
| Maximum power | 16 kW |
| Combustion efficiency | up to 99% |
| Ecodesign class | Class 5 |
| Compatible fuels | A1 wood pellets Ø 6–8 mm, low-quality pellets 6–8 mm |
| Max fuel consumption | 3.67 kg/h |
| Weight | 15 kg |
| Mounting window | Ø 135 mm |
| Min. chamber depth | ≥350 mm |
| Chamber vacuum | 10 Pa |
| Power consumption (operation) | 67 W |
| Power consumption (ignition) | 367 W |
| External feeder length | 0.5 – 4.0 m |
| Power supply | 230 V AC / 50 Hz |
| Technologies | Overpressure Combustion System, Air Blade System, InCroX®, EC Fan, Internal Feeder, X.Board System, X.Gnite System, S.Control Controller, Quick assembly system, Easy combustion chamber maintenance, X.Plug System, Quick Igniter Replacement System, Inlet with fire barrier, Rotating Combustion Chamber System |
wymiary
Dimensions
zestaw
Set
The set includes:
- Revo EC 16kW burner with InCroX® rotary combustion chamber
- S.Control Controller
- External feeder
